Union M-M

The Union M-M is a high-strength pipe fitting designed for various applications, ensuring safety, corrosion resistance, and easy installation in demanding environments.

High Strength

Corrosion Resistant

Wide Temperature Range

お見積もり

OEMカスタム
迅速で安全なロジスティクス

説明
申し込み
仕様
サポート
関連商品

Union M-M

The Union M-M (LT-05C) is engineered using Silica Sol Precision Casting Technology to offer exceptional tensile and yield strength, making it ideal for high-pressure and corrosive fluid delivery systems. With a size range from 1/4" to 4", this versatile pipe fitting is constructed from durable stainless steel (304 and 316 variants) and is suitable for various applications including fuel & oil, agriculture, and fire protection systems. Its easy installation and maintenance, coupled with a wide operational temperature range of -76°F to +572°F, ensures reliability in challenging environments.

特徴

High Strength

With a tensile strength of 485Mpa, the Union M-M withstands high pressure and stress, ensuring long-lasting performance under tough conditions.

Corrosion Resistant

Made from stainless steel 304/316, this fitting offers excellent resistance to rust and corrosion, making it ideal for harsh chemical environments.

Easy Installation

Designed for user-friendly installation, the Union M-M simplifies setup processes in various systems, saving time and reducing labor costs.

Wide Temperature Range

Operational between -76°F to +572°F, this product maintains reliability in both extreme cold and heat, making it suitable for diverse applications.

アプリケーション

燃料・石油

カムロックカップリングは、燃料および石油産業において不可欠であり、石油製品の移送に信頼性が高く漏れのない接続を提供します。クイックコネクト/ディスコネクト機能により、積み下ろし時の安全性と効率が向上します。

農業

フード＆ドリンク

ガス

スペック

1/4"-4"

製品仕様

商品コード	LT-05C
サイズ	1/4"-4"
テクノロジー	Silica Sol Precision Casting Technology
物理的性質	Tensile strength: 485Mpa, Yield strength > 205Mpa, Elongation: 35%
私たちにできること	Stainless steel 304/316/CF8/CF8M/1.4308/1.4433
スレッド	BS21(BSPT&BSPP)、ANSI/ASME B1.20.1(NPT)、DIN2999(R/RP)、JIS B O203/2(PT)、KS BO221/2(PT)など。
Temperature	-76°F to +572°F（-60℃ to +300°C）
表面	Pickling and Peeling
モデル	P-026
形状	イコール

物流と認証

証明書	ISO 9001:2015、IS014001:2015、CE、ROHS、KCなど。
パッケージ	パレット付きカートン/アウトパレット/木箱
ポート	寧波/上海、中国またはリクエストに応じて他のポート。
サンプル	無料サンプルと運賃の提供
配送詳細	各順序の量そして指定に従って小さいorder.Normalの受渡し時間のための速い配達を提供する完全な在庫は沈殿物を受け取った後30から45日からである
汎用アプリケーション	Fuel & Oil, Agriculture, Food and Beverages, Gas

お見積もり

サポート

その他のサポート

インストレーション・ガイド

To install the Union M-M pipe fitting, ensure that the pipe ends are cut cleanly and are free from any debris. Apply the appropriate thread sealant to the threads of the fitting. Align the fitting with the pipes and hand-tighten it initially before using a wrench to secure it further. Ensure that the fitting is not over-tightened to avoid damage. Check for leaks after installation by pressurizing the system gradually.

アフターメンテナンス

よくあるご質問

Looking for answers about Union M-M? Visit our FAQ section for detailed information and expert insights.

お問い合わせ

What materials are used in the Union M-M?

The Union M-M is primarily constructed from stainless steel variants ASTM A351 CF8 (304) and ASTM A351M CF8M (316) for superior strength and corrosion resistance.
What is the temperature range of this product?

The Union M-M operates effectively within a temperature range of -76°F to +572°F (-60°C to +300°C), making it suitable for various high-temperature applications.
Is the Union M-M suitable for corrosive fluids?

Yes, the Union M-M is designed for use in corrosive medium delivery systems due to its corrosion-resistant materials, ensuring durability and safety.
What certifications does this product have?

The Union M-M is certified with ISO 9001:2015, ISO 14001:2015, CE, ROHS, and KC, ensuring compliance with international quality and environmental standards.
Can I request a sample of the Union M-M?

Yes, we offer free samples of the Union M-M. However, please note that freight costs will be collected, and this enables you to evaluate the product before ordering.
